DAHL 150 Explosion-proof Spot Light

$969.87

Certified for Hazardous Locations: The DAHL 150 is UL844 certified for North America, suitable for various hazardous environments including Class I, Div. 1 and Div. 2 groups C, D, Class II, Div. 1 and Div. 2 groups E, F, G, as well as Class III and Marine Marking.

High Efficiency: Emitting 140 lumens per watt, it’s an energy-efficient choice for industrial lighting, delivering excellent value without sacrificing performance or budget.

Durable and Versatile: Built with lightweight Copper-free Aluminum housing and stainless steel hardware integrated with a tempered flat glass lens, it is s weather-resistant and durable. With an IP66 rating and a wide temperature range, it’s suitable for harsh conditions.

In Stock

  • Total

Specifications

Weight 42.99 lbs
Dimensions 19.76 × 14.80 × 13.78 in
Light Source

Availability

7 to 10 Day Production, plus Shipping

Available Finishes

Gray

Color Rendering Index (CRI)

80+

Housing

Powdercoat finish, Copper-free Aluminum

Lens

Clear tempered glass lens

Light Source Included

LED Array Included

Light Source Lumens

21,000

Listings

IP66, ANSI/UL 1598, 8750, UL 844

Mounting

Yoke Mount/U-Bracket Mount

Product Family

DAHL

Rated Life

150,000

System Watts

150

Voltage

120v, 208v, 240v, 277v

Warranty

5-Year Limited Warranty

Product Description

Certified for Hazardous Locations: The DAHL 150 is UL844 certified for North America, suitable for various hazardous environments including Class I, Div. 1 and Div. 2 groups C, D, Class II, Div. 1 and Div. 2 groups E, F, G, as well as Class III and Marine Marking.

High Efficiency: Emitting 140 lumens per watt, it’s an energy-efficient choice for industrial lighting, delivering excellent value without sacrificing performance or budget.

Durable and Versatile: Built with lightweight Copper-free Aluminum housing and stainless steel hardware integrated with a tempered flat glass lens, it is s weather-resistant and durable. With an IP66 rating and a wide temperature range, it’s suitable for harsh conditions.

DAHL Explosion-proof Ratings:

UL844 Marking (North American)

Class I, Div. 1, Groups C, D
Class I, Div. 2, Groups A, B, C, D
Class II, Div. 1, Groups E, F, G
Class II, Div. 2, Groups F, G
Class III
Marine Marking
UL 1598A
ABS
Other Ratings
IP 66
IK 08

Features:

  • 5000K
  • 150 system watts
  • 100-277v
  • 21,000lm
  • 140 lumens per watt
  • Tempered flat glass lens
  • Copper-free aluminum housing with gray powder coat finish
  • Stainless steel hardware
  • 120° beam
  • 70+ CRI
  • -40°F to 131°F
  • 19.76″ x 14.80″ x 13.78″
  • 42.99 lbs

Please be aware that the shipping weight may vary due to the actual configuration of the product. Therefore, the shipping weight may differ from the specified shipping weight shown.

Access Fixtures Warranty

Access Fixtures is proud to assemble high quality, long lasting lighting products which are covered by a 5-year warranty. In accordance with our warranty policy, we will offer repair, replacement, or refund for qualifying claims. Please contact our friendly customer service team, located in Worcester, MA, to address any questions or concerns you may have. We can be reached at 800-468-9925 Monday-Friday 9-5 EST or via email at [email protected]. Click here to view Access Fixtures' complete warranty policy.


Get a Custom Photometric Analysis for Your DAHL 150 Explosion-proof Spot Light Project

A photometric analysis is a custom computer simulation of your particular project. This service provides average footcandles at various heights, max/min (uniformity) ratios, minimum footcandles, light trespass levels, and more. For exacting lighting specifications, a photometric analysis helps you ensure light levels before making a big purchase. One of our lighting specialists will walk you through the process so you know exactly what you will be receiving. Call us at 800-468-9925 or [email protected] for more information about ordering a photometric analysis for your project.

Ready to Order DAHL 150 Explosion-proof Spot Light or Speak to a Lighting Specialist?

You can place your order online, here. Or, if you want additional information, give us a call at 800-468-9925. Does your project require multiple fixtures? Ask us about quantity discounts. Our team of friendly expert lighting specialists is available to provide what you need to purchase fixtures and illuminate your project with confidence.
