Recreation-Level LED Tennis: 4 x Fixtures, 4 x Poles, 29 Avg Footcandles

$9,779.87

The Recreation-Level LED Tennis Package: 4 Fixtures, 29 Avg Fc, 2.64 Max/Min is a recreational level tennis package with a variety of options.

Great Value: This is our lowest cost tennis court lighting option and requires only 4 20′ poles.

Glare-Free Optics: This package features STAM 400 low glare technology for optimal visibility during games.

High Efficiency: This package uses only 1,620 total system watts for almost club level performance.

In Stock

SKU: AF77X(4)ST-LHM400NU + AF33XPARS420AB Categories: ,

Specifications

Weight 100 lbs
Dimensions 30 × 30 × 30 in
Light Source

Availability

2 to 4 Week Production, plus Shipping

Ballast/Driver

Electronic 50/60 Hz

Color Rendering Index (CRI)

70+

Housing

Die-cast aluminum housing with corrosion-resistant polyester powder. Finish meets 1,000-hour salt-spray certification per ASTM B117/ISO 9227:2012. Modular LED design with IP67 rating.

Listings

CE, CuL Listed, RoHS

Rated Life

50,000 Hours

Warranty

5-Year Limited Warranty

Sports Level of Play

Recreation

Pole Height

20 Feet

Number of Poles

4

Number of Courts

1

Average Footcandles

29

Number of Fixtures

4

Max/Min Uniformity

2.64

Voltage

120v, 208v, 240v, 277v, 347v, 480v

Product Family

STAM

Available Finishes

Bronze

Product Description

The Recreation-Level LED Tennis Package: 4 Fixtures, 29 Avg Fc, 2.64 Max/Min is a recreational-level tennis package with a variety of options.

Great Value: This is our lowest-cost tennis court lighting option and requires only 4 20′ poles.

Glare-Free Optics: This package features STAM 400 low glare technology for optimal visibility during games.

High Efficiency: This package uses only 1,620 total system watts for almost club-level performance.

STAM 400 Features:

  • Gray die cast aluminum finish
  • Up to 52,000 lumens
  • EPA of .81
  • Operates from -40 degrees Celsius to 50 degrees Celsius
  • 70+ CRI
  • DLC, UL, CUL, CE, RoHs listed
  • Unique asymmetric reflector
  • 20′ Smooth Aluminum Anchor Base Pole w/4″ Base Cover, 3/4″ Anchor Bolts
  • L70 @ 50,000 hours
  • 184″ x 269″ x 60″
  • 48 lbs
  • 5000K
  • Standard bracket mount
  • 5-year warranty

Options:

  • Bracket to tenon adaptor

Optional Poles

  • 20′ Smooth Aluminum Anchor Base Pole w/4″ Base Cover, 3/4″ Anchor Bolts
  • DIY – Select “No Poles” to provide your own!

All poles come with templates and necessary mounting hardware.
